JIS G3101 SS400 is a common carbon structural steel grade. Other grades of JIS G3101 are ss330, ss490 and ss540. Relevant product types include steel coils, steel plates, steel sections, and steel pipes.
Product Parameters
Product Name | JIS G3101 SS400/SS490/SS540 Carbon Steel Roll |
Production process | hot rolling,cold rolling |
Material Standards | AISI,ASTM,ASME,DIN,BS,EN,ISO,JIS,GOST,SAE etc. |
Width | 45mm-2200mm |
Length | Custom size |
Thickness | hot rolling: 2.75mm-100mm cold rolling: 0.2mm-3mm |
Delivery conditions | rolling,Annealing,Quenching,Tempered or standard |
Surface process | Ordinary,Wire drawing,Laminated film |
chemical composition
Brand | Carbon | Manganese | Phosphorus | Sulphur |
SS400 | - | - | 0.050max | 0.050max |
SS490 | - | - | 0.050max | 0.050max |
SS540 | 0.30 max | 1.60 max | 0.040 max | 0.040 max |
Mechanical properties
Brand | Yield strength | Tensile Strength | |||
≤ 16 | 16-40 | 40-100 | >100 | - | |
SS400 | 245 | 235 | 215 | 205 | 400-510 |
SS490 | 285 | 275 | 255 | 245 | 490-610 |
SS540 | 400 | 390 | - | - | 540 |
Scope of application
JIS G3101 scope of application: JIS G3101 steel plate and other steel grade products are suitable for general structural buildings, such as bridges and ships.
