ASTM A179 is equivalent to China's No. 10 high-quality low-carbon steel. A179 is suitable for cold-drawn high-quality low-carbon seamless steel pipes for heat exchangers and condensers.
Product Parameters
Product Name | A179 Seamless cold drawn low carbon steel pipe | |
Standard | EN/DIN/JIS/ASTM/BS/ASME/AISI etc. | |
Outer diameter | Seamless:1/4"-36" | Welding:21.3mm-3620mm |
Round tube:1/2"-10" | square tube/Rectangular tube：15x15-400x600mm | |
Wall thickness | Seamless:1.25mm-50mm | Welding:1.65mm-65mm |
Length | 3-12 meters, support customization | |
SurfaceProcess | Bright, polished, black | |
Other Services | Machining(CNC), centerless grinding (CG), heat treatment, annealing, pickling, polishing, rolling, forging, cutting, bending, small machining, etc. | |
chemical composition
C | Mn | P≤ | S≤ | Si≤ |
0.06-0.18 | 0.27-0.63 | 0.035 | 0.035 | 0.25 |
Mechanical properties
SteelStandard | Yield strength(Mpa) | Tensile Strength(Mpa) | Elongation(%) |
A179 | ≥180 | ≥ 325 | ≥ 35 |
Scope of application
ASTM A179 covers seamless cold drawn low carbon steel pipe with minimum wall thickness for piping, heat exchangers, condensers and other heat transfer services.
